ESPECIFICAÇÕES TÉCNICAS
Captação de dados
| 1D | All major 1D symbologies, including EAN-13, EAN-8, UPC-A, UPC-E, ISSN, ISBN, Codabar, Code 128, Code 93, ITF-6,ITF-14, Interleaved 2 of 5, Industrial 2 of 5, Standard 2 of 5, Matrix 2 of 5,GS1 Databar, Code 39, Code 11, MSI-Plessey, Plessey. |
| Image Sensor | CCD 1500 |
| Illumination | Red LED (610nm~640nm) |
| Scan Modes | Trigger Mode, Sense Mode, Continuous Mode, Command Trigger Mode |
| Scan Rate | 300 scans per second |
| Depth of Field EAN 13 (13mil) | 50-655mm |
| Depth of Field Code 39 (5mil) | 55-165mm |
| Field of View Horizontal | 40° |
| Scan Angle Roll | 30° |
| Scan Angle Pitch | ±60° |
| Scan Angle Skew | ±60° |
| Minimal Print Contrast | 30% |
Desempenho
| Processor | 0110 Chip |
Características físicas
| Buttons | Trigger |
| Current @ 5VDC Operating | 55±5mA |
| Current @ 5VDC Standby | 21mA±2mA |
| Dimensions (mm) | 163.0×68.4×58.5mm |
| Input Voltage | 5VDC±5% |
| Interfaces | USB |
| Material | PC, ABS |
| Notifications | Beep, LED indicator |
| Weight | 130g (including USB cable) |
Características ambientais
| Operating Temperature | -20℃ to 60℃ (-4°F to 140°F) |
| Storage Temperature | -40℃ to 85℃ (-40°F to 185°F) |
| Humidity | 5%~95% (non-condensing) |
| Electro Static Discharge (ESD) | ±8 KV (contact discharge); ±10 KV (air discharge) |
| IP Rating | IP41 |
Certificações
| Hardware | FCC Part15 Class B, CE EMC Class B, RoHS |
Garrantia
| Standard | 5 years |
