Principais Especificações
| Processor | AMD Ryzen Embedded V1605B Processor |
| System Memory | DDR4 SoDIMM x2, Max. 32GB |
| Graphics | AMD Vega GPU with 8 Compute Units |
| Expansion Interface | PCI Express[x8] x1 |
| Storage Disk Drive | 2.5” SATA SSD x1 |
| Security | fTPM2.0 |
| Wireless Communication |
802.11ac/a/b/g/n(optional), Bluetooth(optional) |
| Power Requirement | DC 12~24V |
| OS Support | Win 10 IoT Enterprise 64-bit / Linux Ubuntu 64-bit |
Entradas e Saídas
| USB | 2x USB 3.1 Type-A, 1x USB 3.1 Type-C, 2x USB2.0 |
| Serial Port | 2x RS-232 |
| Audio | Mic, Line-out |
| LAN | 2x Gigabit Ethernet |
| Audio Jack | Mic, Line-out |
| Video Out | 1x HDMI 2.0, 1x Display Port 1.4, 1x USB Type-C |
| Display | Up to 3840 x 2160 resolution, at 60Hz |
| HDMI | Up to 3840 x 2160 resolution, at 60Hz |
Condições Mecânicas e Ambientais
| Operating Temperature | 0°C ~ 40°C(32°F ~ 104°F) |
| Storage Temperature | -20°C ~ 60°C(-4°F ~ 140°F) |
| Dimension | 197 x 197 x 59.5 mm for main layer 197 x 197 x 44 mm for extension layers |
| Package Size | 300 x 280 x 95 mm |
| Gross weight | 3.3 kg (7.25 lb) in the single layer, 4.0 kg (7.25 lb) in two layer |
| Net Weight | 2.5 kg in the single layer, 3.7 kg in two layers |
| Certifications | CE : EN 60601-1-2: 2015 + A1: 2021 ( V4.1), EN 60601-1: 2007 + A1:2013 +A2:2021 ( V3.2) EN 55032:2015/A1:2020 EN55035:2017/A11:2020( ITE) IEC62368-1:2020+A11:2020 ( ITE) FCC : Part 15B/ Part 18 UL : ANSI AAMI ES60601-1:2005/A1:2012/A2:2021( V3.2) cUL : CAN/CSA-C22.2 No. 60601-1:14 (IEC 60601-1: 2005+A1:2012+A2:2020,MOD) ( V3.2) |
